WEATHERPROOF ANTICORROSIVE DOME CAMERA ENCLOSURE
MATERIAL OF CONSTRUCTION:
DOME IN SS 316L. TOUGHENED WELL GLASS
CABLE ENTRIES: 2 NOS. CABLE GLAND ENTRIES ET ¾” IS PROVIDED FOR THE TERMINATIONS OF THE CABLES.
OVERALL DIMENSIONS: HEIGHT 460MM X Ø325MM (Dia at the Centre)
INSIDE ROOM AVAILABLE FOR PTZ DOME CAMERA HEIGHT 300MM X Ø (DIA) 170MM
THE DIMENSIONS WILL VARY (+-) 20MM
APPLICATIONS:
Weatherproof Dome camera enclosure is used in potentially corrosive areas where normal Dome cameras cannot be installed directly exposing the environment.
Specifications:
Material of Construction: SS sheets of 10, 14 & 19 SWG in 304 grade
Nozzles, Pipes, in SS 304 grade,
Rubber Hose for Water & Air circulation suitable for Water and Air Pressure up to 4.5Kg/cm2. Rubber Hoses in ½” & ¼” to withstand Temperature up to 120º C (See attached table below)
Air Purging System Nozzle is provided.
Toughened glass 150 MM Dia. X 10 mm thick
Gasket on front & rear flanges between the BODY and the Covers.
Degree of Protection IP: 65 as per IS: 13947 (part-I) 1993
Cable Entry from rear flange Cover is provided.
Ambient Temp. in ºC Where HOUSING is installed
TempERATURE IN ºC Inside HOUSING
Input WATER/AIR Temp.ºC
{Area 1} 120 Up to 40 Less than 5
{Area 2} 100 Up to 40 Less than 15
{Area 3} 80 Up to 40 Less than 20
{Area 4} 65 Up to 40 Maximum 30
Overall Dimensions:
Front 220 mm X Rear 220mm X Over all Length 550 mm
Inner shell Ø150-mm, Mid Shell Ø 190–mm,
Height from the Ground level 250mm
We are offering following with the Air/Water cooled Housing
WATER/AIR Cooled Housing in SS 304 Grade for ambient temperature up to 120Deg. Centigrade
IP: 65 protection.
Air purging arrangement, with maximum pressure of 2.5KG/CM2.
Provided with the WATER/AIR cooled housing are Inlet, Outlet Hoses and Air Hose attached to Air Purging Nozzle.
Digital Temperature Indicator along with Temperature Sensor. This will Monitor Temperature inside the Cooled Housing. This is set at 40 Deg. Cent.
